- Square Wave
- 24 Months Warranty
- Charges battery with full current even at 95 Volt
- In-Built Battery Gravity Builder
- 3 Modes Battery Charger
- Powerful Charger
| Appliances/Electronics | No. of Appliances used at the time of power cut | |
|---|---|---|
| A | B | |
| LED TV 40″Â | 2 | 3 |
| LED Bulb 9WÂ | 10 | 11 |
| LED Tubelight 24WÂ | 7 | 4 |
| Fans | 5 | 4 |
| Fridge (250 Litre)Â | 1 | 1 |
| AC (1.5 Tonne)Â | 0 | 0 |
| Total Watt (Consumption)Â | 966Â | 916Â |
| Battery | Backup for 966W | Backup for 916W |
|---|---|---|
| 120Ah Rating | 40 Min | 40 Min |
| 150Ah Rating | 50 Min | 55 Min |
Consideration
- Power Watt considered LED TV 40″ 75W. Fan 1200mm – 80W. Refrigerator- 200W
- Battery time calculated at 75% to 100% of peak load
- Recommended load should be at 75% to 100% of peak load
- Kindly check the rated power consumption before selecting the home UPS
- Square Wave technology
- Capacity 1500VA, Rated Power 1260W
- Rapid battery charging at low input voltage
- Battery Charging commences from low as 95V
- Â Run 1500 VA load on single battery to save additional cost of one battery
- Supports ECO & UPS mode
- Twin socket output for power load as well regular load with intelligent output load optimization feature
- Supports all Battery Types: TUBULAR, FLAT PLATE,SMF & LOCAL
- 24 Month Warranty
Low Voltage Charging
The UPS starts charging batteries even at low mains voltage of 95 Volts. Ideal for rural and other areas where voltage fluctuations are high.
Inbuilt Battery Gravity builder
Unique technology enables charging of deeply discharged battery in high power cut areas. Your battery gets boost charged at the comfort of your home.
Powerful Charging
High power charging circuitry to charge batteries faster than normal UPS.
ECO & UPS mode
In UPS Mode, output voltage is kept in range of 180V to 260V – ensuring safety of sensitive appliances such as computers. In Eco Mode, voltage range is extended thereby reducing battery usage.
Enhanced protection through MCB
World class MCB ensures your UPS and connected loads stay protected from short circuits.
| Online Availability | No |
| Max Charging Current (in Amperes) | 27 |
| Country of Origin | India |
| Marketing By | Luminous Power Technologies Private Limited |
| Net weight (kg.) | 16.5 Kg |
| No. of batteries supported (12V) | 1 N (One Number) |
| Range Name | Eco Watt |
| VA Rating | 1500 VA |
| Technology | Square wave |
| Warranty | 24 Months |
| Dimensions (L*B*H) | 40.2x32x15 CM |
| Contents of Pack | 1 N Inverter, 1 N Warranty card |
| Manufactured By | (A) Luminous power technologies pvt. Ltd |
